The SW-UF4P2LV-056 provides 4 ports 10/100Mbps IEEE 802.3af/at Power over Ethernet with a total of 60 watts of PoE budget, which is an ideal solution to fulfill the demand of sufficient PoE power for network applications. The SW-UF4P2LV-056 is an ideal solution for securing IP surveillance infrastructure. It provides both 802.3af/at PoE functions along with 4x10/100Ba- se-TX ports featuring 15.4-watt 802.3af/30-watt 802.3at PoE in RJ-45 interfaces and extra 2x10/100Mbps UPLINK RJ-45 port to keep a cascade connection with another switch or NVR. For instance, one SW-UF4P2LV-056 can be combined with one 4 channels NVR and 4 PoE IP cameras as a kit for the administrators to centrally and efficiently manage the surveillance system in the local LAN and the remote site via Internet. With data and power over Ethernet from one unit, the SW-UF4P2LV-056 reduces cabling requirements and eliminates the need for dedicated electrical outlets on the wall, ceiling or any unreachable place. A wire that carries both data and power can lower the installa- tion costs, simplify the installation effort and eliminate the need for electricians or extension cords. Providing 4 PoE interfaces, the SW-UF4P2LV-056 is ideal for small businesses and workgroups requiring deploying the PoE for the wireless access points, IP-based surveillance IP phones in any places easily, efficiently and cost-effectively

• Comply with IEEE802.3, IEEE802.3u, IEEE802.3af/at standards

• Support IEEE802.3x full-duplex flow control; support Auto MDI/MDIX

• 4 Ports support 48V-56VDC power to PoE powered devices

• Provide 15.4W or 30W power to powered devices

• Extra 2 Port 10/100Mbps UPLINK RJ-45

• 60 watts PoE budget

• PoE data & power transmission distance up to 100meters

• Port based VLAN for Enhanced Security

• Transmission distance max up to 250meters when VLAN is enabled

• Excellent anti-thunder, anti-static and anti-interference ability Surge Protection: 6KV

• Restart function helps master IC reset whoolly

• External 53VDC/1.25A power adapter included

• Easy and convenient to use, plug & play, no need to configure

• Galvanized housing for stable and durable working life
